Coil Transfer Cart

Automatic charging industrial coil transfer carts are mainly used to transport metal coils, pipes, beams or other round materials. We can design the capacity of the cart, the size of the table, the power supply style according to your working conditions. In order to protect the round cargo from falling, the plant automatic charging industrial coil transfer cart can be equipped with a V-bracket according to the customer’s application requirements. Automatic charging industrial coil transfer cart is an electronic material handling tool for coil transportation. This type of track bogie is usually equipped with a V-shaped or E-shaped frame on the transfer bogie platform. Those V-shaped or E-shaped frames prevent the material from slipping off the rail bogie. V-frame or E-frame can be divided into two types: movable or inactive.

This kind of 20 tons aluminum coil transfer carts moving on cross bay rails is powered by battery, The battery is installed in the cart,and supply DC electricity to the control system, which makes the cart start, stop, go forward, back forward and so on.It is consist of battery,motor, reducer, cart frame, electric appliance, etc.

Electric aluminium coil transfer cart wireless remote control Customizable
Appearance:Table Size, Table Material, Table type, Rated Load, Color, Wheel Base,Detachable structure etc.
Special Function: Hydraulic Lift Table, Dumpling, Climbing, V shape, PLC control system, Automatic Positioning, clamping device, Anti-explosion, Heat-proof function, Weighting system etc.
Safety Device: Alarm light, Emergency stop button, Radar detector, Buffer, V shape support, Guardrails etc.
Special Design: Round corner, Hold pendant box, Lifting hole etc.

5 tons electric coil transfer trolley automatic charging hand operated must be operated and maintained by a dedicated person, and must not be used by non-operators. Before operation, check whether there are any obstacles on the track, and whether the electrical wiring and control switches are safe and reliable. The 5 tons electric coil transfer trolley automatic charging hand operated on the track must ring to start smoothly, pay attention to whether there is an abnormality around, and be ready to stop at any time. There is no collision with the stop at the end of the track. Rapid changes in direction of travel are not allowed. It is strictly forbidden to maintain and clean the 5 tons electric coil transfer trolley automatic charging hand operated during operation. Overloading is not allowed when loading articles. Projects should be evenly distributed. In the event of a sudden power failure, the control switch should be reset to zero. At the end of the work, the power supply must be cut off, the load must be removed and the equipment must be cleaned.

Automatic charging coil transfer cart 30 tons maintenance free batterys are mainly used to transport metal coils, pipes, beams or other round materials. We can design the capacity of the cart, the size of the table, the power supply style according to your working conditions. In order to protect the round cargo from falling, the plant transfer vehicle can be equipped with a V-bracket according to the customer’s application requirements.
The automatic charging coil transfer cart 30 tons maintenance free battery is an electronic material handling tool for coil transportation. This type of track bogie is usually equipped with a V-shaped or E-shaped frame on the transfer bogie platform. Those V-shaped or E-shaped frames prevent the material from slipping off the rail bogie. V-frame or E-frame can be divided into two types: movable or inactive.

20 tons motorized coil transfer trolley move on railway is a kind of trackless material handling trolley. It is powered by storage battery. The battery is installed in the handling trolley.

The 5 tons battery powered coil transfer cart remote control move on cement floor Is A Battery-Powered Transport Handling Flat Trolley Car Device. The Driving Distance Of The Series Of Transport Coil Carts Are Not Limited, And The Requirements For Track Laying Are Not High.
1. The Special Track Load Tonnage That Is Laid On The Ground Is Large.
2. Suitable For Materials To Be Transported Or Transported Within A Fixed Range.
3. Carrying Tonnage, Size, Function Can Be Customized.
4. The Choice Of Power Supply Mode Can Be DC, AC, And Low Voltage.
5. Application Of High Temperature, Cold, Spray Booth, Sandblasting Room, Etc..

The advantages of the remote control coil handling carts are: no cables, not only safer, but also not afraid of smashing, not afraid of hot, does not hinder cross-transportation, easy to realize remote control and automalization, can be driven on curved roads and circular roads, and the number of transformers can be increased without being flat. The limitation of the running distance of the vehicle is very convenient for the transportation plane layout of the plant.

Rail mold handling coil transfer cart warehouse battery motorizeds are available with a number of drive and control systems. Drive systems include gear reducers, shaft drives and single wheel drives. Typical units are equipped with hand-held suspension controls for the operator to control the rail mold handling coil transfer cart warehouse battery motorized back and forth along the track. The average travel speed can be customized to allow the operator to operate the unit on foot with the vehicle. The pendant can be mounted on any of the four corners of the vehicle, allowing the operator to walk along the front of the vehicle during operation. Our rail mold handling coil transfer cart warehouse battery motorizeds also feature semi-automatic and fully automatic control systems to meet the needs of specific applications.

12 tons heavy duty automatic coil transfer cart electromagnetic brake stepless speed, DC motor speed regulation drive technology, multi-wheel hydraulic steering technology and wire control and remote control dual operation mode. Solid rubber wheels operate directly on the ground, operate without site restrictions, and will not damage the ground. Bidirectional drive and 360° in-situ rotation are also possible.
Applications: Aerospace, military, machinery manufacturing, automotive industry, heavy industry manufacturing, mold manufacturing, engineering machinery, shipbuilding, port yards, steel plate distribution, iron and steel metallurgy, mining transportation and other industries.

360 v ac motor coil transfer wagon handing heavy load 8 ton material machine is one of our common and mature
product, which is customized as per customers’ true demand. Such as power supply, operation system,control system, track or no track,steerable, wheelstype, cart framestructure and so on, and then provide proper solution to you.

Coil transfer cart rail transport platforms have become a new favorite in the field of global industrial transportation, and the market is hot, especially workshop transportation. Coil transfer cart rail transport platforms with rolls can run on vertical tracks, “L” tracks, “S” tracks, curved tracks, etc. Only when fully charged, the trailer with roll can operate freely and the operating distance is not limited. coil transfer cart rail transport platforms can be customized to your specified requirements. It can be equipped with hydraulic lifting device, V-frame, U-frame, rubber mat, wooden mat, weighing device, etc. Coil handling and transfer trailers can be used in a variety of occasions, such as explosion-proof, high temperature resistance, rust-proof, ferries, flammable environments, anti-slip and so on.

In order to meet the needs of steel transportation, we have designed a variety of electric power billet coil transfer car for steel plants to make transportation more convenient and use frequent. More importantly, multi-point security protection not only improves the safety factor, but also has been praised by customers around the world.Electric power billet coil transfer car for steel plants can be used for non-short-distance transportation and there is no frequency limit for use.
Its application scope includes port transportation, automotive field, steel, steel, heavy industry, light industry, chemical industry, mining, shipbuilding, engineering, aerospace, coal, nuclear energy, water conservancy engineering and so on. This cable reel blank transfer vehicle obtains AC 380v power through a cable reel device mounted on the bottom of the car. The motor is controlled by a power supply via the AC motor control system. Through the principle, we can make the billet transfer trolley start, stop, forward, backward and so on.

The aluminium product manufacturing industry coil transfer cart on rail uses the battery as the power source to provide power for the DC traction motor and drive the flat car. Aluminium product manufacturing industry coil transfer cart on rail has the following advantages: no insulation requirements for the track, the driving distance is not limited, can drive on curves and turnouts, maneuverable and flexible, can be interchanged between multiple tracks, high safety performance, wide range of application. The car has the advantages of easy to use, strong bearing capacity, durability, convenient maintenance and long service life. The frequent handling of heavy loads in and between factories has become a means of transportation for many enterprises.
